This specification applies to the 42 inch Color TFT-LCD Module T420HVN08.0. This LCD module has a TFT active  matrix  type  liquid  crystal  panel  1,920x1,080  pixels,  and  diagonal  size  of  42  inch.  This  module  supports 1,920x1,080 mode. Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-pixel color is determined with a 8-bit gray scale signal for each dot.

The T420HVN08.0 has been designed to apply the 8-bit 2 channel LVDS interface method. It is intended to support displays where high brightness, wide viewing angle, high color saturation, and high color depth are very important.
